New

PRV 8MB500 Midbass

PRV 8MB500 Midbass

SKU: 8MB500
New

PRV 8MB500 Midbass

PRV 8MB500 Midbass

SKU: 8MB500

  • 8" Midbass - 8 Ohm
  • Ferrite Magnet
  • 95 dB - 500 Watts
$39.91
$49.89

In stock
  • 8" Midbass - 8 Ohm
  • Ferrite Magnet
  • 95 dB - 500 Watts

Free Shipping available on orders over $1,500.00 in the U.S.

View full details

Features

The 8MB500 was designed to provide outstanding durability and strong midbass punch. This 8″ professional loudspeaker midbass is purpose-built to cover the critical low frequency range in a home speaker setup, but also works great as a door speaker in car audio applications.

  • A deep and punchy midbass response along with a strong vocal response
  • PRO audio midbass woofer offers smooth lower response through a punchy mid bass range
  • Natural paper cone and cloth triple roll surround for smooth response
  • Handles 500 Watts, guaranteeing endurance at loudest volumes
  • Impressive choice for high output home, car, and professional audio systems – 8 Ohm impedance

Built with premium components to ensure absolute high sound fidelity, one of which is its compact push terminals, which connect to its silver tinsel lead wires attached to its high temperature CCAW voice coil.

Featuring the latest technology we can increase tremendously the magnet field without huge magnet, making this midbass one of a kind, with large diameter motor, not bulky yet capable of handling high power!

Featuring a naturally damp paper cone and special coated dust cap, makes this professional speaker able to cover a wide range of frequencies from 75 Hz to 7,500 Hz in three-way systems.

Developed to perform well in tight enclosures, its triple roll surround keeps its cone travel linear at high mibdass excursion. The right combination of cone and suspension gives this speaker an excellent human vocal reproduction with dynamic midbass sound.

PRV 8″ Midbass Speaker 8MB500 PRO Audio 500 Watts / 8 Ohm

Technical Details

GENERAL SPECIFICATIONS

*Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range.

**Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to provide a clean signal without clipping or saturation.

***Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.

  • Nominal Diameter 8" (203 mm)
  • Nominal Impedance 8 Ohm
  • Continuous Program Power (RMS)** 500 Watts
  • Program Power*** 500 Watts
  • Max Peak Power*** 1000 Watts
  • Sensitivity 2.83V at 1m95 dB
  • Recommended Hi Pass Crossover" "For Full Power Handling 95Hz** **12db Per Octave Crossover
  • Frequency Response at -10dB 75 - 7,500 Hz
  • Voice Coil Diameter 2" (50 mm)
  • Voice Coil Wire CCAW
  • Voice Coil Winding Depth12.0 mm
  • Former Material Kapton
  • Magnetic Gap Depth 6.0 mm
  • Frame Material Stamped Steel
  • Magnet Type Ferrite

THIELE-SMALL PARAMETERS

  • Equivalent Volume
    • Vas
    • 19.38 l
  • Excursion (mathematical)**
    • Xmax
    • 4.50 mm
  • Free Air Resonance
    • Fs
    • 69.4 Hz
  • Mechanical Factor
    • Qms
    • 21.86
  • Electrical Factor
    • Qes
    • 0.78
  • Total Factor
    • Qts
    • 0.75
  • Cone Area
    • Sd
    • 241 cm²
  • Mechanical Mass
    • Mms
    • 21.91 g
  • BI Factor
    • Bl
    • 8.66 Tm
  • Dc Resistance
    • Re
    • 6.1 Ohm
  • Inductance
    • Le
    • 0.29 mH at 1 kHz
  • Mechanical Mass Without Air
    • Mmd
    • 18.80 g
  • Mechanical Compliance
    • Mms
    • 21.91 g
***Xmax=(Voice coil winding depth-Magnetic Gap depth)/2+ Mgnetic Gap Depth/4

EXTRA INFO

PRV 8MB500 Midbass DATASHEET Download
  • Overall Depth 3.62" (92 mm)
  • Mounting Depth 3.35" (85 mm)
  • Overall Diameter 8.25" (209.5 mm)
  • Front Mount Baffle Cutout 7.17" (182 mm)
  • Net Weight 5.55 Lbs (2.52 kg)
  • Shipping Weight 6.15 Lbs (2.78 kg)
  • Carton Dimensions WxLxH 9.84″ x 9.84″ x 4.33″ (250 x 250 x 110 mm)
PRV 8MB500 Midbass DATASHEET Download
