PRV 12MR2000X v2 Midrange

PRV 12MR2000X v2 Midrange

SKU: SKU:12MR2000X v2

Skip to product information

PRV 12MR2000X v2 Midrange

PRV 12MR2000X v2 Midrange

SKU: SKU:12MR2000X v2

  • 12" Mid Range - 8 Ohm
  • Ferrite Magnet
  • 100 dB - 2000 Watts


In stock

  • 12" Mid Range - 8 Ohm
  • Ferrite Magnet
  • 100 dB - 2000 Watts

Free Shipping available on orders over $1,500.00 in the U.S.

View full details


Built for high efficiency and extreme output capability, the PRV Audio 12MR2000X v2 12” professional midrange driver is perfect for filling in the midbass and vocal range in the largest SPL systems. This powerful driver features a thoroughly vented 4” diameter voice coil on a heat resistant Kapton former to handle 2,000 watts RMS with minimal power compression.

X Series is dedicated to delivering extreme midrange performance, capable of high output and high power handling, while delivering a smooth vocal response.

  • 2,000 Watts RMS with 100 dB efficiency for amazing output capability
  • 6.60 mm xmax allows excellent control to deliver high impact midbass
  • Detailed vocal reproduction, high fidelity response
  • Excellent performance in compact enclosures
  • Extensive venting keeps the 4” voice coil cool improving reliability when pushed to the limit

Extreme car audio enthusiasts will find PRV Audio’s 12MR2000X to be the perfect 12″ midrange door speaker. It is capable of handling up to 2000 watts RMS power (with a suggested 150 Hz, 18 dB/octave high pass filter in place tuned with PRV DSP)!

The large magnet assembly is attached to a sturdy, reinforced cast-aluminum frame.

A Qts of 0.28 and a double roll suspension design allow for a strong response from 400Hz to 300Hz, even at high excursion controlling well its natural paper cone at its 6.60 mm Xmax. Its composite cone is built with non-pressed paper (visible on the back side) for reduced break-up and smooth sound.

The high power handling, combined with 100 dB sensitivity, allows this mid to produce incredible dynamics and low distortion when pushed to incredible output levels.

PRV 12″ Midrange Speaker 12MR2000X v2 2000 Watts / 8 Ohm High Power PRO Audio Loudspeaker

Technical Details


*Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range.

**Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to provide a clean signal without clipping or saturation.

***Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.

  • Nominal Diameter 12″ (305 mm)
  • Nominal Impedance 8 Ohm
  • Nominal Power Handling* 1000 Watts
  • Continuous Program Power (RMS)** 2000 Watts
  • Max Peak Power*** 4000 Watts
  • Sensitivity 2.83V at 1m100 dB
  • Recommended Hi Pass Crossover" "For Full Power Handling 180 Hz** **12db Per Octave Crossover
  • Frequency Response at -10dB 100 – 5,300 Hz
  • Voice Coil Diameter 4″ (100 mm)
  • Voice Coil Wire CCAW
  • Voice Coil Winding Depth18.2 mm
  • Former Material Glass Fiber
  • Magnetic Gap Depth 10.00 mm
  • Frame Material Die cast aluminum


  • Equivalent Volume
    • Vas
    • 39.61 l
  • Excursion (mathematical)**
    • Xmax
    • 6.60 mm
  • Free Air Resonance
    • Fs
    • 64.7 Hz
  • Mechanical Factor
    • Qms
    • 17.19
  • Electrical Factor
    • Qes
    • 0.28
  • Total Factor
    • Qts
    • 0.28
  • Cone Area
    • Sd
    • 573 cm²
  • Mechanical Mass
    • Mms
    • 69.86 g
  • BI Factor
    • Bl
    • 23.19 Tm
  • Dc Resistance
    • Re
    • 5.4 Ohm
  • Inductance
    • Le
    • 0.43 mH at 1 kHz
  • Mechanical Mass Without Air
    • Mmd
    • 62.11 g
  • Mechanical Compliance
    • Cms
    • 0.086 mm/N
***Xmax=(Voice coil winding depth-Magnetic Gap depth)/2+ Mgnetic Gap Depth/4


  • Overall Depth 4.96″ (126 mm)
  • Mounting Depth 4.48″ (114 mm)
  • Overall Diameter 12.28″ (312 mm)
  • Front Mount Baffle Cutout 11.14” (283 mm)
  • Net Weight 26.65 Lbs (12.08 kg)
  • Shipping Weight 28.15 Lbs (12.76 kg)
  • Carton Dimensions WxLxH 13.38″ x 13.38″ x 6.29″ (340 x 340 x 160 mm)
