PRV D4400Ti-Nd Driver

PRV D4400Ti-Nd Driver

SKU: D4400Ti-Nd

PRV D4400Ti-Nd Driver

PRV D4400Ti-Nd Driver

SKU: D4400Ti-Nd

  • 2" Highs Driver
  • Titanium Diaphragm
  • 110 dB - 400 Watts

$229.91
$275.89

In stock

  • 2" Highs Driver
  • Titanium Diaphragm
  • 110 dB - 400 Watts

Free Shipping available on orders over $1,500.00 in the U.S.

View full details

Features

Innovative technology for 4 inch voice coil compression drivers, featuring Powerful neodymium motor for minimal size and weight, allows you to keep a large voice coil without sacrificing performance.

Due to its size and power-to-weight ratio, the D4400Ti-Nd has quickly become the preferred choice among professional users as a “Compact yet very Powerful” driver that solves the critical component weight issue!

Built around a pure Titanium diaphragm, this driver offers the famous PRV Audio crisp high output on high frequency response, with accuracy (from 1,300 to 17,000 Hz) with an emphasis on the critical upper frequency range, from 2,000Hz and up!

  • Pure Titanium diaphragm with large 4″ Voice Coil, providing the lowest possible moving mass with excellent efficiency.
  • Extremely powerful neodymium magnet for minimal size and weight without sacrificing output capability
  • For the highest output audio systems, this 110 dB efficient driver provides competition performance. Mounting hardware is included.
  • 2 Inch Exit Compression Driver with crystal clear, high impact highs response from 1,300 to 17,000 Hz
  • PRO Audio high frequency driver, able to handle 400 Watts Continuous Program Power (RMS) with music for extreme output capability.

Featuring excellent performance and low distortion, this high frequency compression driver is ideal for studio monitors, stage boxes, and sound reinforcement in medium to large rooms.

Due to its high quality in PRO audio, this driver is also one of the top choices for 3-Way custom car audio systems.

The one-piece titanium diaphragm reduces the amount of moving mass, which enhances the driver’s ability to produce clear and crisp high frequencies.

The titanium diaphragm is attached to a 4″ diameter copper-clad aluminum wire with Kapton® former for a high 400 Watts RMS musical power handling, when used with recommended HPF using PRV Digital Signal Processor DSP

  • 1400 Hz at 12 dB per octave filter Crossover / BT12
  • 1200 Hz at 18 dB per octave filter Crossover / BT18

The pure titanium diaphragm of this driver provides crisp output focusing on vocals and high-frequency response, making it our most famous high-frequency driver!

Make your system unique with our colored horns. Available on Single Color, Dual Color, and Dual Tone Finish.

PRV D4400Ti-Nd 2″ High Frequency Neodymium Driver 400 Watts 8 Ohm – Titanium Diaphragm 4” Voice Coil, High Performance and Sensitivity

Technical Details

GENERAL SPECIFICATIONS

*Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range.

**Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to provide a clean signal without clipping or saturation.

***Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.

  • Exit Throat Diameter 2” (50 mm)
  • Nominal Impedance 8 Ohm
  • Nominal Power Handling* 200 Watts
  • Continuous Program Power (RMS)** 400 Watts
  • Max Peak Power*** 800 Watts
  • Sensitivity 2.83V at 1m110 dB
  • Recommended Hi Pass Crossover" "For Full Power Handling 1400 Hz** **12db Per Octave Crossover
  • Frequency Response at -10dB 1,300 – 19,000 Hz
  • Voice Coil Diameter 4” (101.6 mm)
  • Voice Coil Wire CCAW
  • Former Material Kapton
  • Diaphragm Titanium-Mylar
  • Flux Density 1.90 T
  • Magnet Type Neodymium

EXTRA INFO

PRV D4400Ti-Nd Driver DATASHEET Download
  • Overall Depth 2.48” (63 mm)
  • Overall Diameter 6.06” (154 mm)
  • Net Weight 8.82 lbs (4.00 kg)
  • Shipping Weight 9.77 lbs (4.43 kg)
  • Carton Dimensions WxLxH 6.89” x 6.89” x 3.74” (175 x 175 x 95 mm)
  • Mounting Bolt Circle M6 x 4 4” (102 mm)
PRV D4400Ti-Nd Driver DATASHEET Download
