PRV D4500Ph Driver

PRV D4500Ph Driver

SKU: D4500Ph

PRV D4500Ph Driver

PRV D4500Ph Driver

SKU: D4500Ph

  • 2" Midrange Driver
  • Phenolic Diaphragm
  • 108 dB - 500 Watts
$189.91
$237.39

Out of stock

  • 2" Midrange Driver
  • Phenolic Diaphragm
  • 108 dB - 500 Watts

Free Shipping available on orders over $1,500.00 in the U.S.

View full details

Features

Phenolic TRIO Compression Horn Driver
D4500Ph – 500 Watts 8 Ohm 4″ Voice Coil – Bolt-On 2″ Exit – Midrange Vocal Reproduction

The D4500Ph uses the latest Brazilian Phenolic technology TRIO by PRV designed for vocal reproduction. This 2” Exit phenolic compression driver features a 4″ voice coil and new and improved motor that is all about high output and low distortion vocal reproduction all the way down to 450 Hz!

Highlights

  • 108 dB efficient driver is perfect for the highest output audio systems
  • Large 4″ voice coil can handle up to 500 watts max musical power
  • Phenolic diaphragm delivers natural response throughout the vocal range
  • Type Bolt-On – Nominal Impedance: 8 Ohm
  • A Neodymium version is available, D4500Ph-Nd, which reduces the overall size and weight

Brazilian Phenolic Technology Designed For Vocal Reproduction. High temperature CCAW is used for the voice coil that is wound on a Kapton former to withstand high operating temperatures.  The nearly indestructible Phenolic Diaphragm structure, designed for vocal reproduction, allows low midrange reproduction from 450 to 6000 Hz. This driver is recommended for midrange support in multi-way PA’s, stage monitors, side fills and high SPL car audio systems.

The D4500Ph is designed to ensure a quality sound and long lasting play in most any environment. Designed to be the smallest possible without sacrificing any performance in the motor for its 4″ voice coil, we have used a 7.86″ diameter ferrite motor, to keep the smallest size and weight on its category. Car audio SPL enthusiasts use this driver for vocal reinforcement on 3 way systems.

Technical Details

GENERAL SPECIFICATIONS

  • Exit Throat Diameter 2” (50 mm)
  • Nominal Impedance 8 Ohm
  • Rated AES Power Handling (RMS)** 250 Watts
  • Program Power*** 500 Watts
  • Sensitivity 2.83V at 1m108 dB
  • Recommended Hi Pass Crossover" "For Full Power Handling 600 Hz** **12db Per Octave Crossover
  • Frequency Response at -10dB 450 – 6,000 Hz
  • Voice Coil Diameter 4”(101.6 mm)
  • Voice Coil Wire CCAW
  • Former Material Kapton
  • Diaphragm Phenolic resin
  • Flux Density 1.6 T
  • Magnet Type Ferrite

EXTRA INFO

PRV D4500Ph Driver DATASHEET Download
  • Overall Depth 3.66” (93 mm)
  • Overall Diameter 8.66” (220 mm)
  • Net Weight 19.20 lbs (8.2 kg)
  • Shipping Weight 21.16 lbs (8.5 kg)
  • Carton Dimensions WxLxH 5.71” x 5.71” x 3.93” (230 x 230 x 135 mm)
  • Mounting Bolt CircleM6x4 4” (102 mm)
PRV D4500Ph Driver DATASHEET Download
