PRV D3220Ph-Nd Driver
PRV D3220Ph-Nd Driver
SKU: SKU:D3220Ph-Nd
PRV D3220Ph-Nd Driver
PRV D3220Ph-Nd Driver
SKU: SKU:D3220Ph-Nd
- 2" Midrange Driver
- Phenolic Diaphragm
- 109 dB - 220 Watts
In stock
Couldn't load pickup availability
- 2" Midrange Driver
- Phenolic Diaphragm
- 109 dB - 220 Watts
Free Shipping available on orders over $1,500.00 in the U.S.
Features
The D3220Ph-Nd is the perfect solution for mid-high vocal reproduction, offering high sensitivity and a pleasant sound from the phenolic diaphragm. The small diameter of the driver allows front mounting, making it easy to install.
The pro audio phenolic compression driver offers unsurpassed vocal and mid range reproduction. The specially designed phenolic diaphragm on a Kapton former offers a smooth sound required for proper voice production systems.
Technical Details
GENERAL SPECIFICATIONS
- Exit Throat Diameter 2” (50 mm)
- Nominal Impedance 8 Ohm
- Rated AES Power Handling (RMS)** 110 Watts
- Program Power*** 220 Watts
- Sensitivity 2.83V at 1m109 dB
- Recommended Hi Pass Crossover" "For Full Power Handling 800 Hz** **12db Per Octave Crossover
- Frequency Response at -10dB 600 – 7,500 Hz
- Voice Coil Diameter 3”(76.2 mm)
- Voice Coil Wire Copper
- Former Material Kapton
- Diaphragm Phenolic
- Flux Density 1.80 T
- Magnet Type Neodymium
THIELE-SMALL PARAMETERS
EXTRA INFO
- Overall Depth 2.21” (56 mm)
- Overall Diameter 4.88” (124 mm)
- Net Weight 5.00 lbs (2.27 kg)
- Shipping Weight 5.27 lbs (2.39 kg)
- Carton Dimensions WxLxH 5.71” x 5.71” x 3.35” (145 x 145 x 85 mm)
- Mounting Bolt CircleM6 x 4 4” (101.6 mm)
