PRV 12W1600 Woofer

PRV 12W1600 Woofer

SKU: 12W1600

PRV 12W1600 Woofer

PRV 12W1600 Woofer

SKU: 12W1600

  • 12″ Woofer – 8 Ohm
  • Ferrite Magnet
  • 94 dB – 1600 Watts
$189.91
$237.39

In stock
  • 12″ Woofer – 8 Ohm
  • Ferrite Magnet
  • 94 dB – 1600 Watts

Free Shipping available on orders over $1,500.00 in the U.S.

View full details

Features

The 12W1600 woofer features a special 4″ split copper wire voice coil wound on a fiberglass former using proprietary high temperature adhesives. It features an optimized ceramic ferrite magnet assembly that will guarantee very good Low dynamic range with a very low distortion figure. This professional low frequency driver is especially recommended for compact vented enclosures, in which it will deliver solid, deep bass output.

  • 4″ split copper voice coil wound on fiberglass former for hi-temp performance, 8 ohm
  • Ventilated voice coil gap reduces power compression
  • 10.5 mm Xmax, 36 mm peak-to-peak excursion before damage
  • 800 watts continuous program power rating makes high acoustical output
  • High BL factor and Xmax for outstanding Low output
  • Weather-resistant paper cone and dust cap

Designed to make tremendous amounts of bass, the 12W1600 12″ woofer can be used in small vented or sealed cabinet. The shallow 5.51″ mounting depth and high EBP makes it ideal for compact folded horn enclosures. Our specially designed rigid cast aluminum frame features side forced cooling system openings which allows airflow to cool the voice coil to handle up to 800 watts RMS without issue. Spring-loaded push terminals make installation a snap while offering a secure connection to your speaker wires.

To stand up to the use and abuse of the professional sound environment we designed a 4″ spit copper voice coil that is wound inside-outside on a fiberglass former and features a generous 27.5 mm winding length for extended Xmax and less distortion.

The cone, constructed of thick paper for a natural response, includes glass fiber reinforcement and uses a ribbed design offering additional structural support. Supporting the cone is a double heavy spider and triple roll treated cloth surround, both designed for high excursion applications to handle short bursts of excessive power without damage.

Technical Details

GENERAL SPECIFICATIONS

*Nominal power handling is defined as the maximum RMS power that the speaker can handle in a 2-hour test with a pink noise with 6dB of crest factor and a bandpass filter with 12db/oct tuned in its usable frequency range.

**Continuous Program Power (RMS) is the maximum power that the speaker can handle considering a regular musical program using our recommended filters, this power can be used to define the optimum amplifier power to provide a clean signal without clipping or saturation.

***Max Peak Power is the maximum power operation for the speaker, this power is allowed just for a few fractions of a second, usually found just on the peaks of the music. Keeping this power for a little longer timer will damage the speaker.

  • Nominal Diameter 12″ (305 mm)
  • Nominal Impedance 8 Ohm
  • Nominal Power Handling* 800 Watts
  • Continuous Program Power (RMS)** 1600 Watts
  • Max Peak Power*** 3200 Watts
  • Sensitivity 2.83V at 1m94 dB
  • Recommended Hi Pass Crossover" "For Full Power Handling 60 Hz** **12db Per Octave Crossover
  • Frequency Response at -10dB 55 – 2,500 Hz
  • Voice Coil Diameter 4″ (100 mm)
  • Voice Coil Wire Copper
  • Voice Coil Winding Depth27.0 mm
  • Former Material Glass Fiber
  • Magnetic Gap Depth 12.0 mm
  • Frame Material Die Cast Aluminum
  • Magnet Type Ferrite

THIELE-SMALL PARAMETERS

  • Equivalent Volume
    • Vas
    • 46.99 l
  • Excursion (mathematical)**
    • Xmax
    • 10.50 mm
  • Free Air Resonance
    • Fs
    • 51.22 Hz
  • Mechanical Factor
    • Qms
    • 14.98
  • Electrical Factor
    • Qes
    • 0.40
  • Total Factor
    • Qts
    • 0.39
  • Cone Area
    • Sd
    • 594 cm²
  • Mechanical Mass
    • Mms
    • 101.16 g
  • BI Factor
    • Bl
    • 20.35 Tm
  • Dc Resistance
    • Re
    • 5.1 Ohms
  • Inductance
    • Le
    • 1.26 mH at 1 kHz
  • Mechanical Mass Without Air
    • Mmd
    • 92.97 g
  • Mechanical Compliance
    • Cms
    • 0.095 mm/N
***Xmax=(Voice coil winding depth-Magnetic Gap depth)/2+ Mgnetic Gap Depth/4

EXTRA INFO

PRV 12W1600 Woofer DATASHEET Download
  • Overall Depth 6.04” (153.5 mm)
  • Mounting Depth 5.51” ( 140 mm)
  • Overall Diameter 12.40” (315 mm)
  • Front Mount Baffle Cutout 11.16” (283.4 mm)
  • Net Weight 24.22 Lbs (11.0 kg)
  • Shipping Weight 26.01.Lbs (11.80 kg)
  • Carton Dimensions WxLxH 13.38” x 13.38” x 6.69” (340 x 340 x 170 mm)
PRV 12W1600 Woofer DATASHEET Download
